HP Latex 115 Printer

Overview


Model Options

1) Latex 115



The HP Latex 115 is HP’s new entry into the large format market - at 54-inches wide, the L315 is equipped with everything needed to begin producing highly versatile and outstanding graphics for either indoors or outdoor application.

Features

The HP Latex 115 and 315 are comparable in almost every aspect, but there are a few important differences. While the inks themselves are the same, the HP 115 uses smaller cartridges than the HP 315 – the 115’s ink cartridges are 400ml whereas the 315’s are 775ml. The HP Latex 315 also has the OMAS sensor, which helps with skew alignment on media loading and also helps with skew tracking while printing. This is especially useful for larger jobs. And, speaking of larger jobs, the HP 315 enables the user to do “continuous printing”, minimises the curing time between jobs that have the same print parameters.

Video

Specification

Printing

Print speed
48 m²/hr - Billboard (2 pass)
16 m²/hr - Outdoor Plus (6 pass)
12 m²/hr - Indoor Quality (8 pass)
10 m²/hr - Indoor High Quality (10 pass)
6 m²/hr - Backlits, Textiles, and Canvas (16 pass)
5 m²/hr - High Saturation Textiles (20 pass)
Print quality color (best)
Up to 1200 x 1200 dpi
Print technology
  • HP Latex Printing Technologies
Ink types
  • HP Latex Inks
Number of print cartridges
7 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer)
Print heads
  • 6 (2 cyan/black, 2 magenta/yellow, 1 light cyan/light magenta, 1 HP Latex Optimizer)
Print head nozzles
2112
Print repeatability
Average ≤ 1 dE2000, 95% of colors ≤ 2 dE2000
(The color variation inside a printed job has been measured at 10 pass mode on vinyl media within this limit: maximum color difference (95% of colors) ≤ 2 dE2000. Reflective measurements on a 943 color target under CIE standard illuminant D50, and according to the standard CIEDE2000 as per CIE Draft Standard DS 014-6/E:2012. 5% of colors may experience variations above 2 dE2000. Backlit substrates measured in transmission mode may yield different results.)

Media

Finished output handling
  • Roll feed
  • take-up reel (optional)
  • automatic cutter (for vinyl, paper-based media, backlit polyester film)
Media types
  • Banners, self-adhesive vinyls, films, papers, wallcoverings, canvas, synthetics, (fabrics, mesh, textiles and any other porous materials require a liner)
Non-printable area (roll media)
5 x 5 x 5 x 5 mm
Roll maximum input
1
Media width, maximum
1371 mm
Roll maximum weight
25 kg
Roll external diameter
180 mm
Media thickness
Up to 19.7 mil

Dimensions and weight

Minimum dimensions (W x D x H)
2307 x 840 x 1380 mm
Package dimensions (W x D x H)
2553 x 762 x 1252 mm
Weight
174 kg

Environmental ranges

Operating temperature range
15 to 30ºC
Operating humidity range
20 to 80% RH (non-condensing)

Acoustic

Acoustic pressure emissions
54 dB(A) (operating), 38 dB(A) (idle), <15 dB(A) (sleep)
Acoustic power emissions (active, printing)
7.2 B(A) (operating), 5.5 B(A) (idle), <3.5 B(A) (sleep)

Power

Print speed
2.2 kW (printing)
70 W (ready)
< 2.5 W (sleep)

Certifications

Energy star certified
Yes
Environmental certification
  • ENERGY STAR
  • WEEE
  • RoHS (EU, China, Korea, India, Ukraine, Turkey)
  • REACH
  • EPEAT Bronze
  • OSHA
  • CE marking compliant

What's included

What's in the box
  • HP Latex 115 Printer
  • printheads
  • maintenance cartridge
  • printer stand
  • spindle
  • user maintenance kit
  • edge holders
  • quick reference guide
  • setup poster
  • documentation software
  • FlexiPrint BASIC HP Edition RIP
  • power cords
Warranty
1 year provided that the HP Latex End of Installation Registration is completed by an HP authorized reseller
