Overview
Print bigger. Print smarter. Automate more.
The new Mimaki UJF200 Series brings high-quality UV direct-to-object printing to a wider range of products, with the ability to print onto objects up to 250mm high and 20kg in weight.
Available as the UJF200-3042 and UJF200-6042, the series combines high-resolution UV printing, fluorescent colour options and optional camera alignment with the latest RasterLink8 workflow software. The UJF200-6042 can also be configured with a belt feeding system for more automated industrial production.
Coming soon to the UK. Register your interest today.
The Mimaki UJF200 Series is a high-performance UV direct-to-object printing platform designed for businesses looking to expand their product decoration capabilities, increase production efficiency and introduce greater levels of automation into their workflow.
Available in two models, the UJF200-3042 and UJF200-6042, the series combines high-quality UV printing, exceptional workpiece versatility and advanced workflow automation in a flexible flatbed platform.
One of the key advantages of the UJF200 Series is its ability to print directly onto objects up to 250mm high and weighing up to 20kg. This significantly expands the range of products that can be decorated directly, including larger and more dimensional items that may previously have been difficult to process using a UV printer.
Applications can range from promotional products and personalised goods to product decoration and industrial components, making the UJF200 Series suitable for both established print businesses and manufacturers looking to introduce digital direct-to-object printing into their production environment.
High-quality UV printing for demanding applications
The UJF200 Series incorporates highly precise printheads and Mimaki's advanced imaging technology to reproduce fine text, detailed graphics, smooth gradients and high-quality imagery.
With print resolutions of up to 1,800dpi, the printers are designed to deliver the level of detail required for premium product decoration and specialist industrial applications.
Print onto larger and heavier objects
The UJF200 Series is designed to go beyond traditional flat product printing, supporting workpieces up to 250mm / 9.8-inches high and weighing up to 20kg / 44.1lb.
This makes it possible to print directly onto a much wider range of finished products, including carry-on bags, PC cases, electronic housings, product components and other three-dimensional objects.
Fluorescent colours for high-impact printing
Support for fluorescent pink and fluorescent yellow UV inks provides an expanded colour gamut for applications where maximum visual impact is required.
Fluorescent colours can be incorporated into promotional products, personalised goods, product decoration and specialist applications to create vibrant designs that stand out from conventional CMYK output.
Automation designed around production efficiency
The UJF200 Series has been designed with production efficiency and reduced operator intervention in mind.
An optional camera system can automatically detect the position of workpieces and align print data accordingly, reducing the need for manual positioning and setup.
The larger UJF200-6042 can also be equipped with an optional belt feeding system, providing a route towards automated material handling and integration into industrial production environments.
Combined with Mimaki's latest RasterLink8 RIP and workflow software, these technologies provide a more streamlined production process, helping businesses reduce manual setup, improve consistency and increase output.
Key Features:
- High-performance UV direct-to-object printing
- Available as the UJF200-3042 and UJF200-6042
- Maximum printable object height of 250mm / 9.8-inches
- Maximum workpiece weight of 20kg / 44.1lb
- Print resolutions up to 1,800dpi
- Highly precise on-demand piezo printheads
- Advanced imaging technology for fine detail and smooth gradients
- Support for hard and flexible UV inks
- Optional fluorescent pink and fluorescent yellow UV inks
- White and Clear ink capability
- Optional camera system for automatic workpiece detection and print alignment
- RasterLink8 RIP and workflow software
- Automated camera alignment through RasterLink8
- Enhanced job management and workflow automation
- Optional belt feeding system for the UJF200-6042
- Designed to support future automation and industrial production integration
- Suitable for promotional products, personalised goods, product decoration and industrial applications
Features
250MM PRINT HEIGHT
One of the defining features of the UJF200 Series is its ability to print directly onto objects up to 250mm / 9.8-inches high.
This expanded print height opens up applications that would be difficult or impossible to accommodate on many conventional flatbed UV printers, allowing businesses to decorate larger and more dimensional finished products.
Potential applications include carry-on bags, PC cases, electronic housings, product components, promotional products and other three-dimensional objects.
20KG WORKPIECE CAPACITY
The UJF200 Series can accommodate workpieces weighing up to 20kg / 44.1lb, allowing larger and heavier finished products to be printed directly.
The combination of 250mm print height and 20kg workpiece capacity significantly broadens the range of products that can be processed, providing businesses with opportunities to move beyond conventional flat promotional products into larger and more specialist applications.
HIGH-QUALITY UV PRINTING
The UJF200 Series uses highly precise on-demand piezo printheads and Mimaki's advanced imaging technology to produce sharp, detailed and accurate direct-to-object prints.
Print resolutions of up to 1,800dpi allow the printers to reproduce fine text, detailed graphics and smooth gradients with a high level of image quality.
This makes the UJF200 Series suitable for applications where premium print quality is just as important as production flexibility.
DIRECT-TO-OBJECT PRINTING
The flatbed configuration allows products and objects to be positioned directly onto the printer bed and decorated without the need for labels, transfers or other intermediate printing processes.
This provides a flexible solution for both one-off personalised products and larger production runs, while allowing businesses to print directly onto the finished item.
The ability to handle objects up to 250mm high and 20kg in weight further extends the potential application range.
A3 & A2 PRINTING OPTIONS
The UJF200 Series is available in two formats to suit different production requirements.
The UJF200-3042 provides a maximum printable area of 420 x 300mm, equivalent to A3 size, making it well suited to smaller products and applications where a compact production footprint is preferred.
The larger UJF200-6042 provides a maximum printable area of 420 x 610mm, equivalent to A2 size, providing greater capacity for larger products or multiple smaller workpieces within a single print cycle.
FLUORESCENT PINK & YELLOW INKS
The UJF200 Series supports fluorescent pink and fluorescent yellow UV inks, providing additional colour options beyond conventional CMYK printing.
Fluorescent colours can be used to create exceptionally vibrant designs, highlight specific areas of a product or produce distinctive colour effects that help finished products stand out.
This makes the technology particularly useful for promotional products, personalised goods, product decoration, retail products and high-impact specialist applications.
WHITE & CLEAR INK
The UJF200 Series supports ink configurations incorporating White and Clear ink, providing additional flexibility when printing onto coloured, transparent or specialist substrates.
White ink can be used to maintain strong colour reproduction when printing onto darker or coloured products, while Clear ink provides additional opportunities for specialist finishes and effects.
HARD & FLEXIBLE UV INKS
The UJF200 Series supports both hard UV-curable inks and flexible UV-curable inks, allowing the printer to be configured according to the requirements of different applications.
Available ink systems include ELH-100 hard UV ink, ELS-120 flexible UV ink and EFS-150 fluorescent UV ink.
A dedicated PR-200 primer is also available for applications where additional adhesion performance is required on particular substrates.
AUTOMATIC CAMERA ALIGNMENT
An optional camera system can automatically detect the position of workpieces placed on the printer bed and align the print image accordingly.
This can significantly reduce the amount of manual measuring and positioning required before printing, particularly when processing multiple products or workpieces that are not positioned identically.
By automating image positioning, the camera system can help improve production consistency, setup efficiency and operator productivity.
RASTERLINK8 RIP & WORKFLOW SOFTWARE
The UJF200 Series is supported by RasterLink8, Mimaki's latest generation RIP and workflow software.
RasterLink8 introduces enhanced job management and workflow automation, helping users manage print production more efficiently while reducing the amount of manual intervention required.
The software supports automated camera alignment, allowing print data to be accurately positioned according to the detected location of the workpiece. This provides an important part of the automated workflow when the optional camera system is installed.
RasterLink8 also supports the fluorescent-colour workflows available with Mimaki's latest printers, helping users make effective use of fluorescent pink and fluorescent yellow inks to create vivid, high-impact output.
RasterLink8 is compatible with all Mimaki models currently supported by RasterLink7, providing a straightforward upgrade path for users of compatible Mimaki equipment.
OPTIONAL BELT FEEDING SYSTEM
The UJF200-6042 can be equipped with an optional belt feeding system to support more automated production workflows.
The system provides a method of transporting workpieces into and out of the printer and can be integrated with other production equipment to reduce manual handling.
When combined with the optional camera system and RasterLink8 workflow software, the belt feeding system provides a scalable route towards automated industrial production.
AUTOMATION & REDUCED OPERATOR INTERVENTION
The UJF200 Series has been designed with automation in mind, providing businesses with the ability to progressively reduce manual intervention as production requirements increase.
The combination of automated camera alignment, RasterLink8 workflow software and the optional belt feeding system can help automate workpiece positioning, print data alignment and material handling.
This can improve production consistency while reducing the amount of time an operator needs to spend setting up individual workpieces.
IMPROVED PRODUCTION EFFICIENCY
The UJF200 Series is designed to improve overall production efficiency by reducing setup requirements and streamlining the printing workflow.
Mimaki's testing indicates that the UJF200-3042 can achieve approximately twice the production efficiency of the previous workflow under its specified test conditions, based on the total time required for workpiece setup, printing and removal.
This makes the UJF200 Series particularly suitable for businesses looking to increase output while reducing manual production time.
INDUSTRIAL DIRECT-TO-OBJECT PRINTING
The UJF200 Series provides a flexible digital printing platform for manufacturers and print businesses looking to decorate finished products directly.
The combination of high print quality, 250mm workpiece height, 20kg weight capacity, specialist ink options and automation capability makes the UJF200 Series suitable for applications extending beyond traditional promotional product printing.
Businesses can use the technology for short-run product decoration, personalised products, industrial components and other applications where digital printing provides advantages over conventional decoration methods.
HIGH-VALUE APPLICATIONS
The versatility of the UJF200 Series allows businesses to target a wide range of commercial and industrial applications.
Typical applications include:
Promotional products
Personalised products
Product decoration
Industrial components
Electronic housings
PC cases and housings
Carry-on bags
Control panels
Instrument panels
Product components
Novelty products
Short-run customised goods
Specialist product decoration
INK & CONSUMABLES
The UJF200 Series supports Mimaki UV-curable ink systems designed for a wide range of direct-to-object applications.
Available ink systems include ELH-100 hard UV ink, ELS-120 flexible UV ink and EFS-150 fluorescent UV ink.
Ink configurations can include CMYK, Light Cyan, Light Magenta, White and Clear, with fluorescent pink and fluorescent yellow available for enhanced colour expression.
A PR-200 primer is also available for applications where additional substrate adhesion is required.
For information on available Mimaki inks and consumables, speak to the Granthams GT team for advice on the correct products and configuration for your applications.
OTHER MIMAKI MODELS
Mimaki UJF-6042 MkII e — A2-format flatbed UV printer for direct-to-object printing.
Mimaki UJF-3042 MkII e — A3-format flatbed UV printer for compact direct-to-object applications.
The UJF200 Series builds on Mimaki's established UJF platform with enhanced imaging technology, expanded workpiece capability, fluorescent ink options and new automation features.
WHAT IS INCLUDED WHEN YOU BUY A MIMAKI PRINTER FROM GRANTHAMS GT?
We supply new Mimaki printers with the equipment, software and support required to get your production operation up and running.
All new Mimaki equipment purchased from Granthams GT is covered by an official on-site GOLD warranty (parts and labour), supported by Mimaki and Hybrid Services. Equipment is delivered by Hybrid Services in advance of the scheduled on-site installation.
Our engineers are Mimaki-qualified and certified to install and train customers on Mimaki printing equipment. On-site training is provided as part of the installation process, covering day-to-day operation, routine maintenance and the supplied RIP and software where applicable.
We also provide ongoing technical support following installation, helping customers with printer operation, maintenance, RIP software and general troubleshooting.
If you would like to see the UJF200 Series in action before making a purchasing decision, contact the Granthams GT team to discuss demonstration options, availability and the applications you are looking to produce.
Technical Specs
Key Specifications
Models: Mimaki UJF200-3042 / UJF200-6042
Printer Type: Flatbed UV direct-to-object printer
Print Head: On-demand piezo printhead
Maximum Print Resolution: 1,800dpi
Maximum Printable Area UJF200-3042: 420 x 300mm / A3
Maximum Printable Area UJF200-6042: 420 x 610mm / A2
Maximum Workpiece Height: 250mm / 9.8-inches
Maximum Workpiece Weight: 20kg / 44.1lb
Ink Technology: UV-curable ink
Hard UV Ink: ELH-100
Flexible UV Ink: ELS-120
Fluorescent UV Ink: EFS-150
White Ink: Yes
Clear Ink: Yes
Primer: PR-200
Optional Camera System: Yes
Automated Camera Alignment: Yes, with RasterLink8
Optional Belt Feeding System: UJF200-6042
RIP Software: RasterLink8
Interface: Ethernet 1000BASE-T / USB 2.0
UJF200-3042
The UJF200-3042 provides an A3-size maximum print area of 420 x 300mm, making it well suited to promotional products, personalised goods and smaller industrial applications.
Despite its smaller print area, the UJF200-3042 supports workpieces up to 250mm high and 20kg in weight, providing considerable flexibility when printing onto three-dimensional products.
The optional camera system can further simplify product positioning and print alignment, making the UJF200-3042 suitable for businesses looking to increase production efficiency while retaining a flexible direct-to-object workflow.
UJF200-6042
The UJF200-6042 provides a larger A2-size maximum print area of 420 x 610mm, giving businesses greater capacity for larger products or multiple workpieces within a single print cycle.
Like the UJF200-3042, it can accommodate workpieces up to 250mm high and weighing up to 20kg.
The UJF200-6042 can additionally be equipped with the optional belt feeding system, making it particularly suited to businesses looking to integrate direct-to-object printing into a more automated industrial production environment.
PRINTER DIMENSIONS
UJF200-3042: 1,380 x 1,166 x 798mm (W x D x H)
UJF200-6042: 1,680 x 1,166 x 798mm (W x D x H)
Printer weight:
UJF200-3042: 171kg
UJF200-6042: 187kg
BROCHURE
Download the Mimaki UJF200 Series brochure for further information on the printer, available ink configurations, applications and optional automation features.
UK brochure and product information will be added when officially released.
LOOKING FOR A MIMAKI UJF200 SERIES DEMONSTRATION?
Want to see what the new Mimaki UJF200 Series can produce? Contact Granthams GT to discuss your requirements, applications, products and expected production volumes.
Our team can help you determine whether the UJF200-3042 or UJF200-6042 is the right solution for your business and advise on the appropriate printer, ink configuration, automation options and workflow for your applications.
Contact Granthams for Mimaki UJF200 Series pricing, demonstrations and UK availability.
Video
Mimaki UJF200 Series video coming soon.
UK pricing and availability: TBC. Please contact Granthams GT to register your interest in the new Mimaki UJF200 Series.
Overview
Print bigger. Print smarter. Automate more.
The new Mimaki UJF200 Series brings high-quality UV direct-to-object printing to a wider range of products, with the ability to print onto objects up to 250mm high and 20kg in weight.
Available as the UJF200-3042 and UJF200-6042, the series combines high-resolution UV printing, fluorescent colour options and optional camera alignment with the latest RasterLink8 workflow software. The UJF200-6042 can also be configured with a belt feeding system for more automated industrial production.
Coming soon to the UK. Register your interest today.
The Mimaki UJF200 Series is a high-performance UV direct-to-object printing platform designed for businesses looking to expand their product decoration capabilities, increase production efficiency and introduce greater levels of automation into their workflow.
Available in two models, the UJF200-3042 and UJF200-6042, the series combines high-quality UV printing, exceptional workpiece versatility and advanced workflow automation in a flexible flatbed platform.
One of the key advantages of the UJF200 Series is its ability to print directly onto objects up to 250mm high and weighing up to 20kg. This significantly expands the range of products that can be decorated directly, including larger and more dimensional items that may previously have been difficult to process using a UV printer.
Applications can range from promotional products and personalised goods to product decoration and industrial components, making the UJF200 Series suitable for both established print businesses and manufacturers looking to introduce digital direct-to-object printing into their production environment.
High-quality UV printing for demanding applications
The UJF200 Series incorporates highly precise printheads and Mimaki's advanced imaging technology to reproduce fine text, detailed graphics, smooth gradients and high-quality imagery.
With print resolutions of up to 1,800dpi, the printers are designed to deliver the level of detail required for premium product decoration and specialist industrial applications.
Print onto larger and heavier objects
The UJF200 Series is designed to go beyond traditional flat product printing, supporting workpieces up to 250mm / 9.8-inches high and weighing up to 20kg / 44.1lb.
This makes it possible to print directly onto a much wider range of finished products, including carry-on bags, PC cases, electronic housings, product components and other three-dimensional objects.
Fluorescent colours for high-impact printing
Support for fluorescent pink and fluorescent yellow UV inks provides an expanded colour gamut for applications where maximum visual impact is required.
Fluorescent colours can be incorporated into promotional products, personalised goods, product decoration and specialist applications to create vibrant designs that stand out from conventional CMYK output.
Automation designed around production efficiency
The UJF200 Series has been designed with production efficiency and reduced operator intervention in mind.
An optional camera system can automatically detect the position of workpieces and align print data accordingly, reducing the need for manual positioning and setup.
The larger UJF200-6042 can also be equipped with an optional belt feeding system, providing a route towards automated material handling and integration into industrial production environments.
Combined with Mimaki's latest RasterLink8 RIP and workflow software, these technologies provide a more streamlined production process, helping businesses reduce manual setup, improve consistency and increase output.
Key Features:
- High-performance UV direct-to-object printing
- Available as the UJF200-3042 and UJF200-6042
- Maximum printable object height of 250mm / 9.8-inches
- Maximum workpiece weight of 20kg / 44.1lb
- Print resolutions up to 1,800dpi
- Highly precise on-demand piezo printheads
- Advanced imaging technology for fine detail and smooth gradients
- Support for hard and flexible UV inks
- Optional fluorescent pink and fluorescent yellow UV inks
- White and Clear ink capability
- Optional camera system for automatic workpiece detection and print alignment
- RasterLink8 RIP and workflow software
- Automated camera alignment through RasterLink8
- Enhanced job management and workflow automation
- Optional belt feeding system for the UJF200-6042
- Designed to support future automation and industrial production integration
- Suitable for promotional products, personalised goods, product decoration and industrial applications
Features
250MM PRINT HEIGHT
One of the defining features of the UJF200 Series is its ability to print directly onto objects up to 250mm / 9.8-inches high.
This expanded print height opens up applications that would be difficult or impossible to accommodate on many conventional flatbed UV printers, allowing businesses to decorate larger and more dimensional finished products.
Potential applications include carry-on bags, PC cases, electronic housings, product components, promotional products and other three-dimensional objects.
20KG WORKPIECE CAPACITY
The UJF200 Series can accommodate workpieces weighing up to 20kg / 44.1lb, allowing larger and heavier finished products to be printed directly.
The combination of 250mm print height and 20kg workpiece capacity significantly broadens the range of products that can be processed, providing businesses with opportunities to move beyond conventional flat promotional products into larger and more specialist applications.
HIGH-QUALITY UV PRINTING
The UJF200 Series uses highly precise on-demand piezo printheads and Mimaki's advanced imaging technology to produce sharp, detailed and accurate direct-to-object prints.
Print resolutions of up to 1,800dpi allow the printers to reproduce fine text, detailed graphics and smooth gradients with a high level of image quality.
This makes the UJF200 Series suitable for applications where premium print quality is just as important as production flexibility.
DIRECT-TO-OBJECT PRINTING
The flatbed configuration allows products and objects to be positioned directly onto the printer bed and decorated without the need for labels, transfers or other intermediate printing processes.
This provides a flexible solution for both one-off personalised products and larger production runs, while allowing businesses to print directly onto the finished item.
The ability to handle objects up to 250mm high and 20kg in weight further extends the potential application range.
A3 & A2 PRINTING OPTIONS
The UJF200 Series is available in two formats to suit different production requirements.
The UJF200-3042 provides a maximum printable area of 420 x 300mm, equivalent to A3 size, making it well suited to smaller products and applications where a compact production footprint is preferred.
The larger UJF200-6042 provides a maximum printable area of 420 x 610mm, equivalent to A2 size, providing greater capacity for larger products or multiple smaller workpieces within a single print cycle.
FLUORESCENT PINK & YELLOW INKS
The UJF200 Series supports fluorescent pink and fluorescent yellow UV inks, providing additional colour options beyond conventional CMYK printing.
Fluorescent colours can be used to create exceptionally vibrant designs, highlight specific areas of a product or produce distinctive colour effects that help finished products stand out.
This makes the technology particularly useful for promotional products, personalised goods, product decoration, retail products and high-impact specialist applications.
WHITE & CLEAR INK
The UJF200 Series supports ink configurations incorporating White and Clear ink, providing additional flexibility when printing onto coloured, transparent or specialist substrates.
White ink can be used to maintain strong colour reproduction when printing onto darker or coloured products, while Clear ink provides additional opportunities for specialist finishes and effects.
HARD & FLEXIBLE UV INKS
The UJF200 Series supports both hard UV-curable inks and flexible UV-curable inks, allowing the printer to be configured according to the requirements of different applications.
Available ink systems include ELH-100 hard UV ink, ELS-120 flexible UV ink and EFS-150 fluorescent UV ink.
A dedicated PR-200 primer is also available for applications where additional adhesion performance is required on particular substrates.
AUTOMATIC CAMERA ALIGNMENT
An optional camera system can automatically detect the position of workpieces placed on the printer bed and align the print image accordingly.
This can significantly reduce the amount of manual measuring and positioning required before printing, particularly when processing multiple products or workpieces that are not positioned identically.
By automating image positioning, the camera system can help improve production consistency, setup efficiency and operator productivity.
RASTERLINK8 RIP & WORKFLOW SOFTWARE
The UJF200 Series is supported by RasterLink8, Mimaki's latest generation RIP and workflow software.
RasterLink8 introduces enhanced job management and workflow automation, helping users manage print production more efficiently while reducing the amount of manual intervention required.
The software supports automated camera alignment, allowing print data to be accurately positioned according to the detected location of the workpiece. This provides an important part of the automated workflow when the optional camera system is installed.
RasterLink8 also supports the fluorescent-colour workflows available with Mimaki's latest printers, helping users make effective use of fluorescent pink and fluorescent yellow inks to create vivid, high-impact output.
RasterLink8 is compatible with all Mimaki models currently supported by RasterLink7, providing a straightforward upgrade path for users of compatible Mimaki equipment.
OPTIONAL BELT FEEDING SYSTEM
The UJF200-6042 can be equipped with an optional belt feeding system to support more automated production workflows.
The system provides a method of transporting workpieces into and out of the printer and can be integrated with other production equipment to reduce manual handling.
When combined with the optional camera system and RasterLink8 workflow software, the belt feeding system provides a scalable route towards automated industrial production.
AUTOMATION & REDUCED OPERATOR INTERVENTION
The UJF200 Series has been designed with automation in mind, providing businesses with the ability to progressively reduce manual intervention as production requirements increase.
The combination of automated camera alignment, RasterLink8 workflow software and the optional belt feeding system can help automate workpiece positioning, print data alignment and material handling.
This can improve production consistency while reducing the amount of time an operator needs to spend setting up individual workpieces.
IMPROVED PRODUCTION EFFICIENCY
The UJF200 Series is designed to improve overall production efficiency by reducing setup requirements and streamlining the printing workflow.
Mimaki's testing indicates that the UJF200-3042 can achieve approximately twice the production efficiency of the previous workflow under its specified test conditions, based on the total time required for workpiece setup, printing and removal.
This makes the UJF200 Series particularly suitable for businesses looking to increase output while reducing manual production time.
INDUSTRIAL DIRECT-TO-OBJECT PRINTING
The UJF200 Series provides a flexible digital printing platform for manufacturers and print businesses looking to decorate finished products directly.
The combination of high print quality, 250mm workpiece height, 20kg weight capacity, specialist ink options and automation capability makes the UJF200 Series suitable for applications extending beyond traditional promotional product printing.
Businesses can use the technology for short-run product decoration, personalised products, industrial components and other applications where digital printing provides advantages over conventional decoration methods.
HIGH-VALUE APPLICATIONS
The versatility of the UJF200 Series allows businesses to target a wide range of commercial and industrial applications.
Typical applications include:
Promotional products
Personalised products
Product decoration
Industrial components
Electronic housings
PC cases and housings
Carry-on bags
Control panels
Instrument panels
Product components
Novelty products
Short-run customised goods
Specialist product decoration
INK & CONSUMABLES
The UJF200 Series supports Mimaki UV-curable ink systems designed for a wide range of direct-to-object applications.
Available ink systems include ELH-100 hard UV ink, ELS-120 flexible UV ink and EFS-150 fluorescent UV ink.
Ink configurations can include CMYK, Light Cyan, Light Magenta, White and Clear, with fluorescent pink and fluorescent yellow available for enhanced colour expression.
A PR-200 primer is also available for applications where additional substrate adhesion is required.
For information on available Mimaki inks and consumables, speak to the Granthams GT team for advice on the correct products and configuration for your applications.
OTHER MIMAKI MODELS
Mimaki UJF-6042 MkII e — A2-format flatbed UV printer for direct-to-object printing.
Mimaki UJF-3042 MkII e — A3-format flatbed UV printer for compact direct-to-object applications.
The UJF200 Series builds on Mimaki's established UJF platform with enhanced imaging technology, expanded workpiece capability, fluorescent ink options and new automation features.
WHAT IS INCLUDED WHEN YOU BUY A MIMAKI PRINTER FROM GRANTHAMS GT?
We supply new Mimaki printers with the equipment, software and support required to get your production operation up and running.
All new Mimaki equipment purchased from Granthams GT is covered by an official on-site GOLD warranty (parts and labour), supported by Mimaki and Hybrid Services. Equipment is delivered by Hybrid Services in advance of the scheduled on-site installation.
Our engineers are Mimaki-qualified and certified to install and train customers on Mimaki printing equipment. On-site training is provided as part of the installation process, covering day-to-day operation, routine maintenance and the supplied RIP and software where applicable.
We also provide ongoing technical support following installation, helping customers with printer operation, maintenance, RIP software and general troubleshooting.
If you would like to see the UJF200 Series in action before making a purchasing decision, contact the Granthams GT team to discuss demonstration options, availability and the applications you are looking to produce.
Technical Specs
Key Specifications
Models: Mimaki UJF200-3042 / UJF200-6042
Printer Type: Flatbed UV direct-to-object printer
Print Head: On-demand piezo printhead
Maximum Print Resolution: 1,800dpi
Maximum Printable Area UJF200-3042: 420 x 300mm / A3
Maximum Printable Area UJF200-6042: 420 x 610mm / A2
Maximum Workpiece Height: 250mm / 9.8-inches
Maximum Workpiece Weight: 20kg / 44.1lb
Ink Technology: UV-curable ink
Hard UV Ink: ELH-100
Flexible UV Ink: ELS-120
Fluorescent UV Ink: EFS-150
White Ink: Yes
Clear Ink: Yes
Primer: PR-200
Optional Camera System: Yes
Automated Camera Alignment: Yes, with RasterLink8
Optional Belt Feeding System: UJF200-6042
RIP Software: RasterLink8
Interface: Ethernet 1000BASE-T / USB 2.0
UJF200-3042
The UJF200-3042 provides an A3-size maximum print area of 420 x 300mm, making it well suited to promotional products, personalised goods and smaller industrial applications.
Despite its smaller print area, the UJF200-3042 supports workpieces up to 250mm high and 20kg in weight, providing considerable flexibility when printing onto three-dimensional products.
The optional camera system can further simplify product positioning and print alignment, making the UJF200-3042 suitable for businesses looking to increase production efficiency while retaining a flexible direct-to-object workflow.
UJF200-6042
The UJF200-6042 provides a larger A2-size maximum print area of 420 x 610mm, giving businesses greater capacity for larger products or multiple workpieces within a single print cycle.
Like the UJF200-3042, it can accommodate workpieces up to 250mm high and weighing up to 20kg.
The UJF200-6042 can additionally be equipped with the optional belt feeding system, making it particularly suited to businesses looking to integrate direct-to-object printing into a more automated industrial production environment.
PRINTER DIMENSIONS
UJF200-3042: 1,380 x 1,166 x 798mm (W x D x H)
UJF200-6042: 1,680 x 1,166 x 798mm (W x D x H)
Printer weight:
UJF200-3042: 171kg
UJF200-6042: 187kg
BROCHURE
Download the Mimaki UJF200 Series brochure for further information on the printer, available ink configurations, applications and optional automation features.
UK brochure and product information will be added when officially released.
LOOKING FOR A MIMAKI UJF200 SERIES DEMONSTRATION?
Want to see what the new Mimaki UJF200 Series can produce? Contact Granthams GT to discuss your requirements, applications, products and expected production volumes.
Our team can help you determine whether the UJF200-3042 or UJF200-6042 is the right solution for your business and advise on the appropriate printer, ink configuration, automation options and workflow for your applications.
Contact Granthams for Mimaki UJF200 Series pricing, demonstrations and UK availability.
Video
Mimaki UJF200 Series video coming soon.
UK pricing and availability: TBC. Please contact Granthams GT to register your interest in the new Mimaki UJF200 Series.
